Grundfos DMH 5-10 B-PVC/V/C-X-E1U2U2XEMAG Piston Diaphragm
Part number
99587780
- Part number
- 99587780
- Brand
- Grundfos
- Product family
- Pumps
- EAN / GTIN
- 5713831498346
- Price and delivery time on request
- No registration needed
- +39 080 536 7090
Description
Piston diaphragm pumps with external motor or hydraulic drive. The DMH series pump is a versatile positive displacement diaphragm metering pump. The diaphragm is hydraulically coupled to a high efficiency AC motor via a precision gear eccentric tapet system. The metering capacity is adjusted by varying the stroke length on the stroke adjustment knob in a ratio of 1 to 10. The series is extremely versatile, covering a wide flow rate range and offering a variety of dispensing head sizes, materials
Technical data
| Part number | 99587780 |
|---|---|
| Brand | Grundfos |
| Product family | Pumps |
| EAN / GTIN | 5713831498346 |
| Max. flow rate (l/h) | 5 |
| Max. Operating pressure (bar) | 10 |
| Pump housing | Aluminium |
| Dosing head material | Plastic |
| Valve ball | Ceramic |
| Media temperature range | 0 ... 40 °C |
Data supplied by the manufacturer. Please check the specifications against your application before ordering.
