Image for illustration purposes only.
Grundfos DMX 321-6 B-PVC/V/C-X-E1U3U3XEMAG Diaphragm metering pumps
Part number
99206038
- Part number
- 99206038
- Brand
- Grundfos
- Product family
- Pumps
- EAN / GTIN
- 5712608671081
- Price and delivery time on request
- No registration needed
- +39 080 536 7090
Description
The pump from the DMX series is a versatile diaphragm metering pump designed as a positive displacement pump. The diaphragm is mechanically connected to the highly efficient AC motor via a high-precision eccentric tappet gear. The dosing quantity is adjusted by changing the stroke length, which can be set at a ratio of 1:10 on the stroke length adjustment knob. Applies only to pumps with ATEX approval: The dosing pump DMX 226 is approved for operation in potentially explosive atmospheres in acco
Technical data
| Part number | 99206038 |
|---|---|
| Brand | Grundfos |
| Product family | Pumps |
| EAN / GTIN | 5712608671081 |
| Nominal flow rate at 50 Hz | 321 l/h |
| Valve ball | ceramic |
| Maximum operating pressure at 50 Hz | 6 bar |
| Media temperature range | 0 ... 40 °C |
| Rated voltage | 3 x 230/400 V |
| Gross weight | 30.3kg |
Data supplied by the manufacturer. Please check the specifications against your application before ordering.
