Image for illustration purposes only.
Grundfos DDA 200-4 AR-PV/V/C-F-31A7A7BG SMART Digital Diaphragm metering pump
Part number
99159486
- Part number
- 99159486
- Brand
- Grundfos
- Product family
- Pumps
- EAN / GTIN
- 5712607842741
- Price and delivery time on request
- No registration needed
- +39 080 536 7090
Description
SMART Digital diaphragm metering pump with stepper motor drive for low-pulsation and continuous metering. Ideal for complex dosing tasks thanks to integrated dosing monitoring and volume flow measurement. The SMART Digital DDA is a compact positive displacement diaphragm metering pump with variable speed drive (ECM motor) and an adjustment range of up to 1:800. The SMART Digital metering pump series always operates with full stroke length to ensure optimum accuracy and optimal filling of the dos
Technical data
| Part number | 99159486 |
|---|---|
| Brand | Grundfos |
| Product family | Pumps |
| EAN / GTIN | 5712607842741 |
| Max. Flow rate (l/h) | 200 |
| Max. Operating pressure (bar) | 4 |
| Material dosing head | PVDF (polyvinylidene fluoride) |
| Valve ball | ceramic |
| Media temperature range | 0 ... 50 °C |
Data supplied by the manufacturer. Please check the specifications against your application before ordering.
