Image for illustration purposes only.
Grundfos DDE 60-10 B-SS/T/SS-F-31A1FG Metering pump
Part number
99159334
- Part number
- 99159334
- Brand
- Grundfos
- Product family
- Pumps
- EAN / GTIN
- 5712607841225
- Price and delivery time on request
- No registration needed
- +39 080 536 7090
Description
SMART Digital DDE is a compact diaphragm metering pump with variable speed drive (ECM motor) and an adjustment range of up to 1: 800. Thanks to the variable-speed drive, SMART Digital dosing pumps always operate with the full stroke length for optimum dosing accuracy. The ECM motor enables low-pulsation and continuous metering, even at low metering volume flows. The flexible mounting plate allows quick and uncomplicated floor mounting without additional mounting accessories. The adjustment of th
Technical data
| Part number | 99159334 |
|---|---|
| Brand | Grundfos |
| Product family | Pumps |
| EAN / GTIN | 5712607841225 |
| Dosing head | stainless steel |
| Seal | PTFE |
| Valve ball | stainless steel |
| Max. flow rate | 60 l/h |
| Media temperature range | 0..100 V Max. flow rate: 60 l/h |
| Fluid temperature range | 0..50 °C |
| Rated voltage | 1 x 100-240 V |
| Ingress protection | IP65 / NEMA 4X |
Data supplied by the manufacturer. Please check the specifications against your application before ordering.
