Grundfos MTB 65-160/158 A-F-A-BQQE Submersible pump
Part number
98501611
- Part number
- 98501611
- Brand
- Grundfos
- Product family
- Pumps
- EAN / GTIN
- 5711496196317
- Price and delivery time on request
- No registration needed
- +39 080 536 7090
Description
Single-stage close-coupled pump with cast iron casing and impeller and directly flanged standard motor (EFF2). The semi-open impeller is designed for pumping abrasive media with a max. particle size of up to 20mm. Main areas of application: Pump-back stations at WZM Cleaning machines Parts cleaning machines Waste water technology and many more
Technical data
| Part number | 98501611 |
|---|---|
| Brand | Grundfos |
| Product family | Pumps |
| EAN / GTIN | 5711496196317 |
| EAN number | 5711496196317 |
| Nominal flow rate | 60 m³/h |
| Nominal head | 14.7 m |
| Maximum ambient temperature | 60 °C |
| Media temperature range | 0 ... 90 °C |
| Mains frequency | 50 Hz |
| Rated voltage | 3 x 380-415D V |
Data supplied by the manufacturer. Please check the specifications against your application before ordering.
